Educational Electrical Circuit Simulation

This is an Augmented Reality (AR)-based educational simulation experience.

Students can use their smartphones to scan the QR code to launch the 3D immersive experiences application. After launching the application, they can scan the images below, which are designed for Image Tracking AR 3D immersive experiences.

Each scenario will showcase an electrical circuit simulation, demonstrating ON/OFF status, polarity changeover, and battery power increase.

Image Tracking Pictures

Using your Smartphone, Scan the below three scenario Images one by one.

After you scan the QR image, the Image tracking application will open up your smartphone camera and look for images to scan. Point your smartphone to the Scenario 1 image and you will see loading of Electrical Circuit with battery envelope with two battery cells, LED lamp, and Switch. Now, touch the Switch button and enters into ON/OFF interactive mode. With the ON / OFF switch mode, you will notice light bulb glow and no-glow status.

You will learn Polarity in this second scenario. With the initial loading you will see cells are placed with correct polarity order. With the correct + and - sign polarity placing of battery cells, the light will glow. Now, you focus and touch the battery envelop lower over battery cell portion area. With this interaction, the battery position will be swapped with wrong polarity and you will notice change of + and - sign. With the wrong polarity placing of battery cell, the light will NOT glow.

In this third scenario, focus and click on the battery envelope region. You will be seeing battery envelope with one battery cell and another slot is with metal rod connected without battery cell. In this loading state, the light glows dim because of less power from one battery cell. With the interactions touching on the empty battery cell, you will see placing second battery cell and light glows brighter. In the second state with interaction, the bulb glows brighter because of two battery cells.
